Page 305 - Williams GREEN Parts Catalog 16-9932

Unique Assemblies > cont'd
ROAD SHOW (50024)
$
$
!
Shaker Assembly
A-19169
Item Part Number Description Associated Parts:
1 A-12565 Front Mounting Bracket Item Part Number Description
2 A-19217.1 Motor Mounting Bracket
3 14-7951 Motor 11 03-8256-1 Plastic Shaker Guard
4 20·9588 Eccentric Weight (2) 12 4408-01119-00 Nut 8-32 ESNA (2)
5 02-4353 Spacer 13 4700-00023-00 FW .203 x .625 (2)
6 01010659 Insulator-Washer 14 16-8587-960 Caution Label
7 4008-01017-06 MS 8-32 x 3/8 P-RH-S (4)
8 4008-01076-06 SS 8-32 x 3/8 Hex (4)
9 4408-01119-00 Nut 8-32 ESN (2)
10 H-12541 Motor Cable Assembly
6)f~® ELECTRONICS GAMES, INC. 5-69
