ROAD SHOW (50024)
Unique Assemblies - cont'd
Pop-Up Assembly
A-18794
Item Part Number
Description
Item Part Number
Description
A-19225
Pop Up Bracket
&
Switch Assy.
2 k)
03-7066
Coil Tubing
a) A-19324.1
Weldmen! - Pop Up
m)
01-7695
Solenoid Bracket
b) 5647-12693-20
Mini Micro Switch
n)
A-12390
Flipper Stop Bracket
c) 01-8600
Switch Insulator
p)
10-422
Spring
d) 01-8240
Nut Plate #2-56
q) A-18818
Separator Assembly
e) 4002-01105-07
MS, #2-56 x 7116~
r)
4008-01003-05
MS, 8-32x
5/16~
f) 5070-09054-00
Diode 1N4004 1.0A
s)
4010-01008-06
MS, 10-32 x
3/8 ·
g) 5647-12693-61
Mini Micro Switch
3
4008·01003-05
MS, 8-32 x
5/1S·
h) 23-6686
Round Pad
4
H-19526
Cable
2
A-19226
Pop Up Bracket
&
Coil Assy.
a) A-19325
Pop Up Coil Bracket
b)
AL-26-1500
Coil Assembly
c) 03-7067
Coil Tubing
d)
10-135
Plunger Spring
e) 23-6420
Rubber Grommet
f) 01-9784
Coil Mounting Bracket
g) A-17797
BeIl Armature Assembly
h) 4408-01119-00
Nut, 8-32 ESN
j)
AE-24-900
Coil Assembly
6)f~®
ELECTRONICS GAMES, INC.
5-67
