DELTRONICS
120 Liberty Lane
Chalfont, PA 18914
(215) 997~8616
Optional Kits
&
Accessories ~ cont'd
Ticket Dispensers·
Pinball
Pinball
Part Number
Description
60204 60404
Sys 11 WPC~R
A~14206
PC Board ~WPC
x
A~14365
PC Board ~WPC
x
C~13427
PC Board ~ System 11
x
H~13426
Interconnect Cable Assembly
x
H·13460
Motor Control Cable Assembly
x
H~14370
Motor Cable Assembly
x
H~15218
Widget Driver Cable Assembly
x
H·16594
Power Cable Assembly
x
5795-12851-00
Ribbon Cable, 34 Pin
x
16·6107
Instruction Manual
x
16-9487
Instruction Manual
x
Miscellaneous Hardware and Parts:
Kit Quantity
01-9538
Plate - Hole Cover
1
1
02-4176-18
Spacer M-F 8-32
x
1·118 Hex
4
03·7722·4
Kwik Klip 1/4"
2
2
03·8088·1
Display Support 3/8"
4
4
11-932
Board Spacer
1
1
RM·27·02
Slip Hose Sleeve 1/4" dia.
13"
13"
4310-01123·08B
Carriage Bolt 10-24 x
1/2
Black
1
1
4310-01123-16B
Carriage Bolt 10-24 x 1 Black
6
431 O~O1123~20B Carriage Bolt 10-24
x
1-1/4
Black
6
4320-01123-18
Carriage Bolt 1/4·20 x 1·1/8
4
4
4410·01128·00
Nut 10-24 Keps
6
6
4420·01141-00
Nut 1/3-20 Flangrip
4
4
4700-00121 ~OOB
FW
1/4 x 5/8 x
1/32
Black
6
6
*Ticket Dispenser - With outside mount case, Deltronics Part #TDOM-l0
"Ticket Dispenser - With outside mount case and low indicator,
Deltronics Part #TDOM~L-l 0
5-48
CiJ'f~®
ELECTRONICS GAMES,INC.
