Page 275 - Williams GREEN Parts Catalog 16-9932

Coil Sleeves and Associated Coil Assemblies
con Sleeve India Star Road Demo Flint Dirty
Part Number Coil Assembly Part Number SOO17 50023 50024 50028 50029 50030
Game and Part Quantity
AE~23-800 Yellow 2
AE-25-1000 Brown 2
03-7066 AE-26-~200 Green 4 4 6 6 4 6
(~-3/4") AE-26-1S00 Blue 1
AE-27-1200 White 2
Al-26-1S00 Blue 1
03-7066-3
(1-7/8") AE-26~1500 Blue 2
03-7066-4 AE-24-900 Red 1
(2-3/32") AE-26-1200 Green 2 1 1
AE-23-800 Yellow 1 1 1 1 1 1
FL-11629 Blue 2 3 2 3 3
FL-11638 Red 1
03-7066-5 FL-12722 Green
(2-7/32") 1
FL-11753 Yellow 1
FL-11753-1 Yellow 1
FL-15411 Orange 2
AE-23-800 Yellow 5 1 1
AE-24-900 Red 1 1
03-7067 AE-26-1200 Green 1 1
(1-27/32") AE-26-1S00 Blue 1 1
AE-28-1S00 Blue 1
AL-2S-1000 Brown 1
AL-26-1500 Brown 1
AE-23-800 Yellow 1 1 1 2 2
03-7067-5 AE-26-1500 Blue 1 1 1 1 1 1
(2-1/16") AE~27-1200 White 4
AE-28-1S00 Blue 1
Coil Sleeves (Tubing)
Typical Coil Assembly
AE-23-800 shown
03-7066- 03-7067-
6)f'~® ELECTRONICS GAMES, INC. S-39
