Kicker Assemblies
India Star
Road Demo
Flint
Dirty
Part Number
Description
50017 50023 50024 50028 50029 50030
Game and Part Quantity
A-14525
Kicker/Bracket Ass'y (Shooter)
1
1
1
1
A-17234
Bottom Arch Kicker Assembly
1
Kicker Bracket Assembly
A~14525
Item Part Number
Description
A-6306-2
Bell Armature Assembly
2 A-14526
Kicker Mounting Brk! Ass'y
3
01-8-508-T
Solenoid Bracket
4 10-135
Solenoid Spring
5 23-6420
Rubber Grommet
6
AE-23-800
Coil Assembly
7
03-7067-5
Coil Tubing
8
4008-01017-04 MS 8-32 x
1/4
P-RH-S (2)
9
03-8523
Insulator
Bottom Arch Kicker Assembly
A-17234
hem Part Number
H-17237
B-11873
A-6306-2
B-7409-2
01-8-508-T
10-135
AE-23-800
Description
Cable Assembly
Coil Sub-Assembly
Bell Armature Ass'y
Kicket Mounting Brkt Ass'y
Solenoid Bracket
Solenoid Spring
Coil Assembly
Coil Tubing
MS 8-32 x 5/16 P-RH-S (2)
2
a)
b)
c)
d)
f)
g)
h)
03-7067-5
4008-01017-05
O)f~®
ELECTRONICS GAMES, INC.
5-33
