Jet Bumper Coil Assembly
Jet Bumper Coil Assembly
A-19415-2
Item Part Number
Description
1 8-7417
Bracket & Stop Assembly
2 01-1747
Coil Retaining Bracket
3 01-5492
Armature Link, Steel
4 01-5493
Armature Link, Bakelite
5 02-3406-1
Coil Plunger
6 10-326
Armature Spring
7 AE-26-1200
Coil Assembly
8 4006-01017-04 MS 6-32 x 1/4 P-RH-S (2)
9 03-7066
Coil Tubing
Associated Assembly:
10 B-12030-2
leaf
Switch Assembly
a)
A-16443
Switch & Diode Ass'y
b)
01-1168
Switch Mounting Bracket
c)
01-3670
Switch Plate
d)
03-7395
Switch Actuator
e)
4005-01003-12 MS 5-40 x 3/4 P-PH-S (2)
f)
4405-01117-00 Nul 5-40 Hex (2)
