5-20
Diverter Assemblies - cont'd
19
17
19
8
Ramp Diverter Assembly
n
A-19746
Item Part Number Description
1 A-19747.3
2 AE-26-1200
3 A-18583.1
4 A-11397
5 01-8413
6 02-4831
7 01-12993
8 01-13623.1
9 02-5145
10 03-7066
Item Part Number
Description
Diverter Mounting Plate
Coil Sub-Assembly
Diverter Act. Shaft Assy
Stop Bracket Assembly
Coil Mounting Bracket
Shaft Diverter Actuator
Plate - Diverter Shaft Act.
Diverter
Shaft - Diverter Pivot
Coil Tubing
11 10-395
Spring
12 20-8712-43 ~E"-Ring,
7/16~
Shaft
13 20-871
s-s
RonPin, 1/8 x
7/16~
14 4323-01158-06 SS 1/4-28 x 3/8" Cup Point
15 4004-01003-05 Mach. Screw, #4-40x 5/16"
16 07-6688-20N Rivet, 1/8 x 1/2"
17 4408-01119-00 Nut #8-32 ESNA
18 H-19775
Divertor Cable
19 0,.,3626
Stop Plate Bracket
20 RM-23-02 Heat Shrink Tubing
1/4"
Poly
CiJ'f~®
ELECTRONICS GAMES,INC.
