Ball Popper Assemblies - cont'd
Rotor Lock Ball Popper Unit Assembly
A-16231
Item Part Number Description
1. A-16230 Ball Popper Sub-Assembly
2. AE-26-1200 Coil Assembly
3. 03-7067 Tubing Coil
4. 10-135 Solenoid Spring
5. 23-6420 Rubber Grommet
6. A-168S8 Mounting Bracket
7. A-13270 Bell Armature Assembly
8. 4408-01119-00 Nut, 8-32 ESN
9. 4106·01013-06 Sh. Metal Screw, #6x3/8 P-PH Type 2S
10. A-16808 LEO Assembly, RTV
11. A-16809 Photo Trans. Assembly. RTV
12_ H-16229 Cable Assembly
O)f~® ELECTRONICS GAMES, INC. 5-5
