Page 239 - Williams GREEN Parts Catalog 16-9932

Ball Eject Assemblies - cont'd
Ball Eject Assembly ~Special
A~17073
Associated Parts:
usm Part Number Description Item Part Number Description
1. A-6949-R Spring Plate Assembly 11 B-9362-L-t
2. A-826B Mounting Bracket Assembly a) 8-7572-1
3. A-7471-R Eject Cam Assembly b) 01-8-508-5
4. 02-2364 Plunger Coil c) 4006-01017-06
5. 10-320 Spring - Eject d) 4406-01119-00
6. 12-6227 Hair Pin Clip (2) e) AE-26-1200
7. 4700-00030-00 Flatwasher, 17/64 x 112 x 15ga. f) 03-7066
8 4700-00103-00 Flatwasher, 17/64 xll2 x 28ga. 12. 10-128
9. 03-8085 Armature link 13. 03-7351-1-9
10. 20-8716-5 Roll Pin,1/8x 7/16"
Coil & Bracket Assembly
Bracket & Stop Assembly
Coil Retaining Bracket
Mach. Screw, 6-32 x 3/8
Nut, 6-32 ESN
Coil Assembly
Coil Tubing
Spring
Eject Shield
6)f~® ELECTRONICS GAMES, INC. 5-3
