Page 215 - Williams GREEN Parts Catalog 16-9932

Wire Ball Guides and Ball Gate Wireforms
India Star Road Demo Flint Dirty
Part Number Description 50017 50023 50024 50028 50029 50030
Game and Part Quantity
Straight Wireforms:
12-6466-2 Wire Ball Guide, 1/2" 4
12-6466-6 Wire Ball Guide, 1-1/2" 1 2
12-6466-8 Wire Ball Guide, 2" "1
12-6466-10 Wire Ball Guide, 2-1/2" 1
12-6466-15 Wire Ball Guide, 3-3/4" "1
12-6466-18 Wire 8all Guide, 4-1/2" 1
12-6468 Rebound Wire, 3-1/8" x 1/2" 2 2
12-6882-1 Wire Hinge Pin 1
(Used on B/Guide A-18229, p. 3-20)
12-7247-1 Wire Ball Guide, 112" x 2" 1
12-7247-2 Wire 8all Guide, 1" x 2" 1 .
Bent/Curved Wi reforms:
12-7107 Wire Ball Guide 1
12-7108 Wire Ball Guide 1
12-7115 Gate Wireform 1
(Used on Ramp A-l6863, p. 3-39)
12-7173 Actuator Wire 1
(Used on Ramp A-I7771, p. 3-51)
12-7217 Gate Wireform 1
(Used on B/Guide A-l8829, p. 3-23)
12-7238 Gate Wireform 1
(Used on B/Guide A-19252, p. 3-25)
12-6466- 12-6468
6)f'~® ELECTRONICS GAMES, INC.
