Page 200 - Williams GREEN Parts Catalog 16-9932

(50030)
Wireform and Ball Gate Locations
Wireforms and Ball Gates
Item Part Number Description
1 12·6842 Bottom Arch Wire Fence
2 12·7227 Ball Popper Wire Ramp
3 12·7256 Cross Over Wire Ramp
4 A-19710·1 Ball Gate Assembly, Left
5 A·19710-2 Ball Gate Assembly, Righi
6 12·7237.1 Ball Popper Wire Ramp
7 ·A·19252 Ball GuideflNire Assembly
a} 12·7238 Ball Guide Wire
8 A·19265 Switch Gate Assembly
9 12·7228.2 Diverter Wire Ramp
10 A-19637 Gun Load Ramp Assembly
a) 12-7229.2 Wire Ramp
'See p. 3-25 for complete drawing and
p.4-24 for wire.
