Outhole Ball Trough Assemblies - cont'd
Outhole Ball Trough Assembly
A-18753
Item Part Number
Description
Ikm
Part Number
Description
1 A-16809-2
Bal! Trough Welded Ass'y
11 4008-01017-05 MS 8-32 x 5/16 P-RH-S (2)
2 01-11587
Ball Trough Front
12 4408-01119-00 Nut 8-32 ESN (4)
3
A-6306-2
Bell Armature Assembly
13 4008-01017-06 MS 8-32 x 3/8 P-RH-S (4)
4 AE-26-1500
Coil Assembly
14 23-6702
Bumper Plug
5 01-8-508-T
Solenoid Bracket
15 A-18617
7 IR LEF PCB Assembly
6 03-7067-5
Coil Tubing
16 A-18618
7-IR Opto PCB Assembly
7 10-135
Spring
17 4006-01 003-10 MS 6-32 x 5/8 P-RH-S (6)
8 23-6420
Rubber Grommet
18 23-6626
Rubber Grommet (6)
9
03-8523
Insulator
19
4700-00004-00 FW 9/64 x 7/16 x 21 gao (6)
10 01-11586
Coil Mounting Bracket (Bell)
20 02-4975
Bushing (6)
Outhole Ball Trough Assembly
A-19963
(Parts listed replace same items as A-187S3)
Item Part Number
Description
15 A-18617-1
71R LEF PCB Assembly
16 A-18B18-'
7-IR Opto PCB Assembly
