DEMOLITION MAN (50.028)
Ramps - cont'd
2
i
f
tG:
Feed Ramp Assembly
A-17771
Item Part Number
Description
Item Part Number
Description
A-18172
Welded Feed Ramp Ass'y
8
5070-09054-00 Diode 1N4004, 1.0A
2
H-1B080
General Switch Cable Ass'y
9
4002-01105-08 MS 2-56 x
1/2
P-PH-S (2)
3
01-12318
Ramp Flap
10 01-8600
Insulator
4
07 -6688-17N Rivet 5/32 x 1/8, Nickel (2)
11 01-8240
Nul Plate #2-56
5
5647-12693-11 Mini Micro Switch
12 4006-01003-08 MS 6-32 x
112
P-PH-S
6
01-10636
Switch Cover Clip
13 4406-01117-00 Nul 6-32 Hex
7
12-7173
Wireform Switch Actuator
O)f~®
ELECTRONICS GAMES, INC.
3-51
