INDIANA
JONES
(S0017)
Ramps
Ball Trough Assembly
A·16317
Item Part Number
Description
Item Part t'1!umber
Description
1
01·11178
Ball Trough Bracket
10 4010·01006-0B MS #10-32 x
1/2
P-PH-S
2
03-8523
Insulator
11 01-11393
Plunger Guide Bracket
3
A-16909
RTV Opto PIT Ass'y (2)
12 10-135
Spring
4
A-1690B
RTV Opto LED Ass'y (2)
13 4006-01 003-04 MS #6-32 x
1/4
P-PH-S (4)
5
4106-01013-06 SMS #6
x
3/8 P-PH (B)
14 4410-01132-01 Nut #10-32 ESN (2)
6 02-4791
Coil Plunger
15 20-8712-43
'E' Retaining Ring
7
03-7066-3
Coil Tubing,
1-7/B'
16 20-8790
Nylined Bearing
8
AE-26-1500
Coil Assembly
17 H-16873
Cable Assembly (not shown)
9
A-16575
Stop Bracket Assembly
18 OH1062
Shield Insulator
O)f~®
ELECTRONICS GAMES, INC.
3-37
