Page 124 - Williams GREEN Parts Catalog 16-9932

Ball Guides
Item Part Number Description
1 A-13204-50024 BOUomArch Assembly
2 A-18575-1 Left Flipper Ball Gd Ass'y
3 01-12984 Ball Guide
4 01-12965.1 Ball Guide
5 01-12913.1 Ball Guide
6 A-19322.1 Ball Guide Assembly
7 01·12948 Ball Guide
8 01-12955 Ball Guide
9 A·19320 Ball Guide Assembly
10 01-12947 Ball Guide
11 A-19321 Ball Guide Assembly
12 A-19319 Ball Guide Assembly
13 01-12911.3 BarrGuide
14 A-19318 Ball Guide Assembly
15 01-12958.1 Ball Guide
16 A-19323.1 Ball Guide Assembly
17 01-12963 Ball Guide
18 A-19356 BaHGuide Assembly
19 A-18575-2 Right Flipper Ball Gd Ass'y
Mounted under Bottom Arch Assembly:
20 A-19277 Ball Guide Assembly
21 A-19276 Ball Guide Assembly
(50024)
Ball Guide Locations
5 ® ®
3-4 CiJ'f~® ELECTRONICS GAMES,INC.
