Lower Rear Door - Cabinet Base
-11-877-- ..
Upright Video Cabinet - cont'd
Rear Access View
and
Printed Circuit Board Locations
=-\--- t r--;;::;'" Venthole Covers
(2 used)
Power "Oli/Off" Switch
Rear Ooor - Monitor Box
11-875
----+-- Cam Lock
Upper Rear Door - Control Panel
11-876
Item Part No. Description
1 C-11879 -3036
2 C-12037
3 C-12218
4 C-12260-3036
5 C-12350.
6 C-12401-1
7 0-12446
8 5014-12363-00
Sys. Z CPU PCB Assembly
Sys. Z 1/0 PCB Assembly
Sound Power Supply Assy.
Sys. Z Rom-2 PCB Assembly
Sys. Z Sound-2 Board Assembly
Power Supply Switching Assy.
Transformer Power Pack
Potentiometer 10K n
10-2 ELECTRONICS GAMES. INC.
