Coin Door Assembly
09-17002-
09-17003-
Item Part Number
DHcrtptlon
Quantity
1 27-1038
BunonCover
20r3
2 27-1041-1-54
Price Panel
20r3
3 27-1026-1-15
Coin Entry Plate
20r3
4 27-1016
t,.ock Assembly
1
5 27-1061·1
Coin Retum - Bezel
1
6 27-1062
CoIn Retum Rap
1
7 27-1021
Button Housing - 2·sIot
1
27-1022
Button Housing - 3-sIot
1
8
27-1111
Intertock SWitch
1
9 27-1006-1
Coin Ooor , 2-Set
1
27-1007-1
CoIn Ooor • 3-SIot
1
10 27-1005-
Coin Door Frame
1
11 27·1003
MlC
Screw. 6-32 x
3116
4
12 27-1008
Diagnostic SWitch
1
13 27-1101
MlC
Screw. 4-40 x
1/4
2
14 27-1102
Bracket, Diagnostic SWitch
1
15 27-1037
Bunon
20r3
16 27·1078
MlC
Screw, 6-32 x 318
20r3
17 27-1039
Conical Spring
2or3
18 27·1079
Self-tapping Screw, t6 x
1/4
2
19 27-1077-1
CoInbox Cover
1
20 27-1066
Slam Switch
1
21 27·1067
MlC
Screw, 4-40 x 112
2
22 27-1017
Nut (key)
1
23 27-1012
locking
Cam
1
24 27-1011
locking Arm
2
2S 27-1020
Washer
1
26 _ 27-1018
StarWasMr
1
27 27·1019
wcScrew
1
28 Not Used
29 Not Used
30 27-1112
CoIn Inlet Chut.
20r3
31 27-1088
Wreaan,.
20r3
32 27-1025
K.yHook
20r3
33 27-1086
Washer, t6
20r3
34 27-1078
MlC
Screw, 6-32 x 318
20r3
27-1078
hVC
Screw, 6-32 x
718
20r3
35 27·1079
Self-tapping Screw, t6 x 114 20r3
36 27·1084
Lamp Socket
20r3
27·1085
Lamp
20r3
37 27-1096
Self-tapping Screw,
IS
x 318
20r3
38 27-1087
!WC
Screw, 6-32 x 518
20r3
39 27-1082
Lever Arm
20r3
40 27-1097
Switch Cover
20r3
41 27-1091-1
Coin Accept Chute
20r3
42
27-1075
Wire Form
20r3
27·1093
WlreFonn
20r3
43 27-1094
MlC
Screw, 6-40 x 7/8
2
44
27-1087
MlC
Screw, 6-32 x 5/8
2
4S 27·1086
Washer, t6
2
46 27-1095
Nut, 4-40
2
47 27-1076-1
Coin Retum Box
1
48 27-1078
WC
Screw, 6-32 x 318
2
49 27-1092
Microswitch
20r3
9-10b
ELECTRONICS GAMES. INC.
