D-I0745-2 (2-SLon COIN ~
DOI'IESTIC AND CANADIAN GAtES
Index
Pert
Index
Part
No.
No.
Description
No.
No.
Description
1 904581
Coin Door Frame
25 400-4
Nut
2
404341
Coin Door
26 904583
Coin Return Lever
3 904587
Coin Door Inner Panel
27 108B5-4 Screw
4 905484
Coin Return Door
28 904936
A.P.F: Bar Keeper
5 904590-2 Coin Return Bezel
29 905928
Spring
6 904588-2 Coin Inlet Bezel (Used with
* 30 404603
C.R.E.M. Coil Assembly
Figure 1)
( 10/12vdc)
905425-4 Coin Inlet Bezel (Used with
404603-1 C.A.E.M. Coil Assembly (6vdc)
Figure 2)
404603-2 C.R.E.M. Coil Assembly
7 404734
Button Assembly (Used with
(24vdc)
Figure 1)
404603-3 C.R.E.M. Coil Assembly
404604
Button Assembly (Used with
(24vac)
Figure 2)
404603-4 C.R.E.M. Coil Assembly
8 903494
Spring
(48vac)
9 404897
5/8-lnch Tubular Key Lock
404603-7 C.R.E.M. Coil Assembly
404767
7/8-lnch Flat Key Lock
(12vac)
404766
15/16-lnch Tubular Key lock
404603-9 C.R.E.M. Coil Assembly
with Spacer
(l17vac)
10 904719
Pivot Arm for 5/8-lnch Flat
31 905927
C.R.E.M. Core
Key Lock
32 404602
Armature Assembly
904719-1 Pivot Arm for
7/8-lnch
Flat
33 904598-1 Coin Return Box
Key Lock
34 904935
A.P.F. Bar.
904719-2 Pivot Arm for
15/16-lnch
35 5301-13 25¢ NORYL Acceptor
Tubular Key Lock
563-20
25¢ Metal Acceptor
11 904718-1 Universal
Locking Arm (2)
36 905417
Switch and C.R.E.M. Bracket
12 325-4-4
Screw
37 904701
Coin Chute
13 906030
Identification Label
38 904845
Coin Switch
14 404352
Counter Assembly (6vdc)
39 904710
25¢ Switch Wire
404352-1 Counter Assembly (12vdc)
40 900651
Switch Wire Retainer
15 904822
Slam Switch Insulation
41 404353
25¢ Coin Switch Assembly
16 904782
Test Switch with Hardware
42 100-4-12 Screw
17 904712
"U" Type Fastener
43 904762-1 Switch Cover
18 904704
Slam Switch Assembly
44 904700
Switch and C.R.E.M. Bracket
19 116-4-8 Screw
*45 404354
C.R.E.M. Assembly
(10/12vdc)
20 404645
Coin Inlet Chute Assembly
404354-1 C.R.E.M. Assembly (8vdc)
21 904716
Lamp (6.3 volt)
404354-2 C.R.E.M. Assembly (24vdc)
904716-1 Lamp
(12114
volt)
404354-3 C.R.E.M. Assembly (24vac)
904716-2 Lamp (24 volt)
404354-4 C.R.E.M. Assembly (48vac)
904716-9 Lamp P20 vott)
404354-7 C.R.E.M. Assembly (12vac)
22 904717
Lamp Socket
404354-9 C.R.E.M. Assembly (117vac)
23 110-4-6 Screw
46 100-6-4 Screw
24 904722
Wire Key Holder
*
Index No. 30 used with Index No. 36 only.
Index No. 45 (Alternate Style) used with Index No. 44 only.
