Rollover Wire Assembly
(With Related Parts)
8-n52-L (shown) or s-n52-R
T
e
Switch Acluator Wires
12-6470-L & -R
18
Solder Lug - Flat
5825 -06523-00
'----See Switch notes
I
!
Dioae 1N 4001
_-.I
5070-06258-00
'---
Switch Limit Bracket
01-3797-2
Strike Zone
Alley
Cats l1e Tae Str Gold Mine Top Dawg
Assembly Part No.
1916
1918
1919
1920
1921
Game and Part Quantity
B-n52-L
16
16
20
20
20
B-7752-R
20
20
16
16
16
Switch Notes:
1. SW-1A-128-L - Single Make Switch with side lug mounted left. used with B-77S2-l (14 per game).
2. SW-1A-128-R - Single Make Switch with side lug mounted right, used with B-77S2-R (10 par game).
3. SW-1A-129-l - Double Make Switch with side lug mounted left, used with B-77S2-l (2 par game).
4. SW-' A-129-R - Double Make Switch with side lug mounted right, used with B-77S2-R (2 per game).
ELECfAONICS GAMES, INC.
8-13
