F-14 TOMCAT (CONTINUED)
F-14 Launch Ramps Assemblies
&
Parts
Item Part No.
Description
1
C·11356
Launch Ramp Assembly
2 H·11598
Cable Assembly
3 24-6549
Bulb,1I44
4 03·8063-1
Sleeve, Blue
5 03,8063·4
Sleeve, Red
6 5647·12073·01 Micro Sw~ch
a) 01,8467
Swilch Insulator
b) 01·8240
Nut Plate. 2·56
C)
4002 -0 1052 -08 Mach. Screw. 2-56 x
1/2.
SL·PH
7 12·6714
Wire Ranv. Top
8 12·6712
Wire Ramp. Middle
9
12·6713
Wire Ramp. Bottom
Launch Ramp Diverter Assembly
Incl udi ng pin 0·11352, and associated parts
Item Pari No.
Description
1 C·11355
Diverter Chassis
2 C·11354
Diverter Arm & Shaft
3 20·8712·25
E·ri"g. 114shah
4 4008·01017·06
Mach. Screw. 8-32
.3/8,
P·RH-S
5 A-11614
Solenorc Stop Bracket
6 AE-26-1500-02
Solenoid Assembly
7
02·4292
Solenoid Plunger
8 01·8531·3
Coil Support Bracket
9 10·398
Coil Spring
10 20·6712-43
E-ring,
7/15
shalt
11 A-11353
Drive Arm Assembly
12 20-8716-2
Roll Pin.
3132
x 518
13 01-8625
Insulating Bracket
14 A·11595
Solenoid Stop Bracket Assembly
15 01·8598
Coil Support Bracket
16 02·4291
Coil Pive! Pin
17 20-8712-18
E·ri"g. 3116 shalt
ELECTRONICS GAMES. INC.
5-19
