RAI'F LI FTING tECHANISI'1
N ""~'SN ~
4408·01119·00
I
/--@@
Washer
/
e'_--A-~:b."~
i
!
\1'00 " 00
@-
I /
I
I
L _ _
9
10
Ramp
Lifting
Mechanism
Including pIn B
a
11138
t
and other associated paris
Item Part
No.
Description
Hem Part No.
Description
1 A·11137
Lift Crank Assen"t>1y
15
Not Used
2
4406-01119·00 Nut, 6·32 ESN
16
Not Used
3 A-80S0
Plunger Assembly
17 4008-01021-07 Mach. Screw. 8-32 x
7f16
4 4700-00073-00 Washer, .281 i.d x SOOo.d. 18 4701 -00003-00 Lockwasher, #8 Split
5
12-6227
Retaining Clip
19
4700-00089-00 Washer .. 172 i.d. x
7/16
o.d.
6 10-128
Spring
20 8-11141
Lift Mech Bracket Assembly
7
01-8-508-S
Coil Retaining Bracket
21 A-6892
Frame and Eyelel
8
4006-01017 -OS Mach. Screw, 6-32 x:318
22 SM-2S-600-DC Coil Assembly
9
AE -24-900-02 Coil Assembly
23 A-11139
Armature Assembly
10 8-7572-1
Bracket & Stop Assembly
a) A-8936
Armature Subassel'l"bly
11 4004-01003-10 Mach. Screw. 4-40 x 518
b) 01-8390
L Crank Lock
12 5070-06258-00 Diode, 1N4001
c) 4006-01003-03 Mach Screw, 6-32 x 3/16
13 A-7438-'
Terminal Strip
24 10-363
Extension Spring
14 5647-12001·00 Microswitch
25 12-6227
Retaining Clip
ELECTRONICS GAMES.
INC.
5 -13
