BANZAI RUN
(566)
PLAYFIELD CIRCUIT BOARD LOCATIONS
(underside of playfield)
BACK80X CIRCUIT BOARDS
(w/Upper Playfield removed)
I~§\
-
-
1
Item Part No.
Description
1 C·12040
a-Lamp PC Board
2 0·12042
, 1-Larnp PC Board
3 C·12139
4-Lamp PC Board
4 C-12043
6-Lamp PC Board
5 0-12041
13-Lamp Lamp PC Board
UPPER PLAYFIELD
6 0-12146
Marquee Score Display
&
(viewed as tilted onto
Lamps PC Board
Lower Playfield)
7 0-12144
Marquee Flashers PC Bd.
S
0-12247
Aux Power Drive Board
9 0-11883-566
System 11B CPU Board
10 0-12112
Interconnect Board
Item Part No.
Description
11 0-11581
Audio Board
12 0-8345-566
Power Supply Board
13 C-11902-1
Relay PC Board
ELECTRONICS GAMES. INC.
1-4g
