Page 357 - Williams BLUE Parts Catalog 16-9064-B

SEO Version

Section 5 - Electro-Magnetic Devices
Contents
Ball Eject Assemblies
5-1 to 5-2a
Ball Shooter Lane Feeder Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . .. 5-2b to 5-3
Coil and Sleeve Assemblies
5-4 t05-4b
Drop Target Assemblies:
Single Bank
5-5 to 5-7
Three Bank
5-8,5-8a
Four Bank
'. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 5-Bb
Five Bank
5-8c
Flipper Assemblies
5-Sd to 5-9
Jet Bumper and Jet Bumper Coil Assemblies . . . . . . . .. .
5-1 0, 5-10a
Coil and Bracket Assemblies.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 5-1 Ob, 5-10c
Ball Kicker Arm and Kickbig Arm Assemblies
5-1 Od to 5-1 Og
Out hole Kicker Assemblies (Ball Release) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 5-10h
Outlane Kickback Assemblies
5-11, 5-12
Plunger Assemblies.
. . .. . . .. . . . . . . . . .. . . . . . . . . . .. . .. . . . . . . . .. .. . 5-12a, 5-12b
Ramp Lifting Mechanism. . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . .. . . . . .. .. . .. . .. 5-13
Unique Parts for Specific Games:
Grand Lizard (523)
5-14
Sorcerer (532) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 5-14
High Speed (541)
5-15
Pin Bot (549) ......... ..........•.............................
5-16, 5-17
F-14 Tomcat (554) ....•......................................
5-18 to 5-20
Minionaire (555)
5-21
Space Station (552)
5-23, 5-24
Taxi (553)
,
5-25, 5-26
Fire! (556)
5-27 to 5-30
Big Guns (557)
'. .
5-31, 5-32
Swords of Fury (559) . .. .. . .. .. .. .. .. .. .. .. .. .. . .. .. .. .. . .. .. . . .. ...
5-33
Cyclone (564}
5-34, 5-35
Banzai Run (566) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-36 to 5-38
Black Knight 2000 (563) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 5-39 to 5-41
Jokerz! (567)
,
5-42,5-43
Earthshaker! (568)
5-44 to 5-48
Police Force (573) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-49 to 5-52
ELECfAONICS GAMES, INC.
5-i
