Rollover Wire and Bracket Assemblies ~cont'd
_ Quantity
Game
Assembly Number
Description
Per Game
JOKERZI (567)
5647-12073-01
A~11991
Switch
&
Diode Assy.
5
a} 5070-06258-00
Diode 1N4001
(See p. 4-36b)
b) 5647-12073-01
Micro Switch
(Used on R-12279)
'.
(Mini Playfield)
5647~12073-19
A·12245
Rollover Switch Assy.
S
a) 03-8173
Switch Holder
(See p. 4-36c)
b) 0070-06258-00
Diode 1N4001
c) 5647-12073-19
Micro Switch
5647-12133-01
A-11608
Kicker Switch Assembly
2
a) A-7438-1
Terminal Strip
(See p. 4-36b)
b) 01-7151
Switch Bracket
c) 5070-06258-00
Diode 1N4001
d) 5647-12133-01
Micro Switch
EARTHSHAKER (568)
5647-12073-04
A-11619
Shooter Lane Sw Assy.• -
1
(See p. 4-36a)
(See p. 6-6h)
5647-12073-19
A-12508
-.
Micro Switch Assembly
g.
a)01-8719
..
Mounting Bracket
.,.
(See p. 4-36c)
bl5070-06258-00 .
Diode tN4001
c} 5647-12073~19
Micro Switch
POLICE FORCE (573)
5647-12073-04
A-11619
Shooter Lane Sw Assy.
1
(See p. 4·36~)
(See p. 6-6h)
5647·12073-19
A-12688
Sub-Mini-Switch Assy.
7
a) 01·8719
Mounting Bracket .
(See p. 4-360)
b) 5060-06258-00
Diode 1N4001
c) 5647-12073-19 . Micro Switch
5647-12133-04
R-12787
Outer Ramp Assembly
1
(See p. 4-36c)
(See p. 3-111)
