Ball Gate Assemblies - cont'd .
POLICE FORCE (573)
Quantity
Part Number
Description
Per Game
(S~e p..4-34g)
A-8244-R
Ball Gate Assembly
1
(See p. 4-34c)
A-11760
Ball Shooter Gate Assy.
1
(See p. 4-34j)
A-12160
Ban Shooter Gate Assy.
1
(See
p.
4-34k)
A-12558
Switch Gate Assembly
1
A-12782
a) 01-9052
b)
0s-n96-1
c) 12-6824
d) 12-6870
Switch Gate Assy. - Outer
Mounting Bracket
Plastic Washer
Switch Gate Wire
Switch Actuator Wire
1
J
A-12783
a) 01-8888
b)
03-n96-1
c) 12-6847
d) 12-6870
Switch Gate Assy. -Inner
Mounting Bracket
Plastic Washer
Switch· Gate Wire
Switch Actuator Wire
1
J
2
6-12267
a) 01-6991
b) 12-6802
Ball Gate Assembly
Mounting Bracket'
Sail Gate Wire
4-34m
