Page 31 - Williams BLUE Parts Catalog 16-9064-B

Item Part No. Description
1 C·119l7·l 5-Lamp, 2-Flash PC Board
2 C-11865 3-Lamp PC Board
3 C-11849 14-Lamp PC Board
4 C-11904 5-Lamp PC Board
5 C-11864 4-Lamp PC Board
6 C-11902-1 Relay PC Board
7 C-ll998·1 Relay PC Board
8 C-11866 3-Lamp PC Board
9 C·11998-1 Relay PC Board
10 C·11863 7-Lamp PC Board
11 C-11318-1 3-b Drop Target Opto Assy.
12 C-11903-R t-b Drop TargetOpto Assy.
SPACE STATION (552)
PLAYFIELD CIRCUIT BOARD LOCATIONS
(underside of playfield)
ELECTRONICS GAMES. INC. 1--4a
