POLICE FORCE (573)
Wireform, Ball Gate and Spin Target Locations
Item Part No.
Description
1 8-12807
Wire Ramp & Switch Assy.
2 A-12783
Center Ramp Ball Gate Assy.
3
12-6466-6
Wireform.
1-1/2"
(3 used)
4
A-12160
Ball Gate Assembly
5 A-8244-R
1-Way Ball Gate Assembly
6-
12-6466-5
Wireform,
1-1/4" .
7
B-12267
Eject Ball Gate Assy. (2 used)
8 A-12782
Ball Gate Assembly
9
A-12558
' Ball Gate Assembly
10 8-12785
Spin Target Assembly
11 A-11760
Shooter Lane Ball Gate Assy.
12 12-6466-7
Wireform, 1-314"
13 A-8645
Rollover Wire & Brkt Assy.
14 A-5844-44
Rollover Wire & Brkt Assy.
15 12-6542
Ball Return Gate Wire
16 12-6468
Anti-,Rebound Wire
17 12-6842
Bottom Arch Fsnee
