Page 273 - Williams BLUE Parts Catalog 16-9064-B

SEO Version

BANZAI RUN (566)
Wireform, Ball Gate and Spin Target Locations
Lower Playfield
Item Part No.
Description
1 12-6784
Wireform
2 B-12164
Spin Target Gate Assy.
3 A-12254
Ball Gate Assembly
4
A-8244-L
Left Ball Gate Assembly
5 A-12120
Ball Gate Assembly
6 A-8244-R
Right Ball Gate Assembly
7 12-6466-2
Wireform, 1/2"
8 A-12216
Ball Gate Assembly
9 12-6466-9
Wireform,
2-114"
10 A-8645
Rollover Wire
&
Brkt Assy.
11 A-5844-44
Rollover Wire
&
Brkt Assy.
12 A-5844-45
Rollover Wire
&
Brkt Assy.
13 12-6542
Ball Return Gate Wire
14 12-6468
Anti-Rebound Wire
o
0 0 0
o
0
o
Upper Playfield
15 A-12171
Ball Gate Assembly
