Page 264 - Williams BLUE Parts Catalog 16-9064-B

F-14 TOMCAT (554)
WIREFORMS - BALL GATES - SPIN TARGET LOCATIONS
Item PIN Description
12-6468 Anti-Rebound Wire
2 A-5844-35 Rollover Wire & Brkt. Assy.
a) 01-3411 Bracket
b) 12-6459-1 Rollover Wireform
3 12-6725 Ba 11 Guide Wire,
(Curved, 4-7/8")
4 A-11632 Ball Gate Assy.
a) 01-8624 8all Gate Bracket
bJ 12-6731 Ball Gate Wireform
5 8-11342 Wire Ramp & Switch Assy.
al 12-6713 Wire Ramp (Lower)
6 8-11617 Ball Gate Assy. (Center
Left Eject)
al 12-6736 Gate Wire
b) 01-8487 Kicker Mtg. 8rkt.
7 8-11346 Wire Ramp & Switch Assy.
a) 12-6712 Wire Ramp (Middle)
8 12-6730 Ball Guide Wire,
(Curved, 4-13 /16)
9 8-1134 Wire Ramp & Switch Assy.
a) 12-6714 Wire Ramp (Upper)
10 A-11550 Ball Gate Assy.
al 0.1-8592 Ball Gate Bracket
b) 12-6620 Switch Actuator Wire
c) 12-6733 Ball Gate Wireform
11 12-6466-12 Ball Guide Wire, 3"
12 12-6706 Wireform, Top Loop:
(Curved, 9-1/2")
13 12-6710 Wire Chute, Ball Shooter
Lane
14 12-6711 Wire Ramp, Ball Popper
15 12-6708 Ball Guide Wire,
(Curved, 2-41164" )
16 A-11551 Ball Gate Assy.
a) 01-8593 Ball Gate Bracket
b) 12-6620 Switch, Actuator Wire
c) 12-6734 Ball Gate Wire
17 B-9655-554 Spin Target Assy.
a) 01-7649 Spin Target Mtg.
b) 03-7796 Plastic Washer
c) 12-6620 Switch Actuator Wire
d) 31-1019-554 Screened Spin Target
e) 31-1424-1 Spin Target Decal (Front)
f) 31-1424-2 Spin Target Decal (Rear)
18 12-6732 Ball Guide Wire,
(Curved, 6-9/16" )
19 12-6466-5 Ball Guide Wire, 1-1/4"
