Page 256 - Williams BLUE Parts Catalog 16-9064-B

SORCERER (532)
WIREFORMS - BALL GATES - SPIN TARGET LOCATIONS
Item PIN Description
1 12-6468 Anti-Rebound Wire
2 A-58<t4-35 Rollover Wire ~ 8rkt. Assy.
al 12-6459-1 Rollover Wireform
3 12-6466-7 Ball Guide Wire, 1-3/4"
4 12-6466-8 Ball Guide Wire, 2"
5 8-9655-532 Spin Target Assy.
al 01-7649 Spin Target Mtg.
bl 12-6620 Switch Actuator Wire
c 1 31-1019-532 Screened Spin Target
6 12-6466-12 Ball Guide Wire, 3"
7 A-8244-L Ball Gate Assy. , L.
al 01-6935 Ball Gate
b 1 01-6938 Ball Gate Brkt.
c) 02-2413-1 Gate Hinge Pin
8 A-8244-R Ball Gate Assy. , R.
al 01-6935 Ball Gate
bl 01-6938 Ball Gate Brkt.
cl 02-2413-1 Gate Hinge Pin
9 12-6651 Ball Guide Wire,
(Curved, 7-5/16" l
10 12-6625 Upper Ball Chute Wire
11 12-6626 Lower Ball Chute Wire
12 12-6466-16 Ball Guide Wire, 4"
13 A-5844-32 Rollover Wire ~ Brkt. Assy.
al 12-6449 Rollover Wireform
14 B-I0922-2 Ball Guide Wire &: Post Assy.
a) 02-4175 Gate Post
bl 12-6644 Gate Wire,
(Curved, 6-7/16 ")
15 A-9465-R Ball Gate ~ Wire Assy. , R.
a) 01-6991 Ball Gate Brkt.
b) 12-6565 Ball Gate Wire
16 12-6466-11 Ball Guide Wire, 2-3/4"
17 12-6466-9 Ball Guide Wire, 2-114"
18 12-6466-4 8all Guide Wire, 1"
19 A-5844-46 Rollover Wire ll. 8rkt. Assy.
a) 12-6544 Rollover Wireform
20 A-8645 Rollover Wire & 8rkt. Assy.
a) 12-6581 Rollover Wireform
21 A-5844-44 Rollover Wire ~ Brkt. Assy.
a) 12-6546 Switch Wire
22 12-6542 Anti-Rebound Gate Wire
Note: Items 20 thru 22 are located under-
neath the bottom arch.
4-2 ELECTRONICS GAMES. INC.
