Page 25 - Williams BLUE Parts Catalog 16-9064-B

SECTION 1 - ELECTRONICS
Connectors
Cable Assemblies
Electrical Devices
Plugs and Jacks
Printed Circuit Boards
CONTENTS
Printed Circuit Board
Road Kings (542).
Pin Bot (549) •.
F-14 Tomcat (554) •
Millionaire (555)
locations:
Printed Circuit Boards & Electrical Devices located in the
Back Box for Pinball Games .••••...••
Back Box Layout for Pinball Games. • • ••.
C-9939 Flipper Power Supply Board •••••
Printed Circuit Boards Located on the Insert Board .•
C-11233 Lamp Resistor Board Assembly .••••
0-11581-554 Background & Speech Board ••••
Printed Circuit Boards Located on the Speaker Display Panel.
0-11415 Alphanumeric Display Unit Board
0-11609 Alphanumeric Display Unit Board
Transformer Cables ••••
Plugs & Jacks . . . • • . . . . • •
Player Score Display Panels for Pin Ball Games •.
Player Score Display & Speaker Assemblies for Pin Ball Games ..
Light Bulb & Socket Assemb lies • • • . .• • •
Printed Circuit Boards Located in the 8ackbox for Shuffle Alley
Games'. . • • .• • • • iI • • •
Player Score Display Panels for Shuffle Alley Games
Shuffle Alley Cable Assembi ies. • • . . . .•.
ELECfAONICS GAMES, INC.
1-1
1-2
1-3
1-4
1-5
1-6
1-6
1-7
1-7
1-8
1-9
1-9
1-10
1-11
1-12
1-13 - 1-15
1-16
1-17
1-18
1-19
1-20
