RAMPS AND CHUTES
F-14 TOMCAT (554)
Launch Ramp Assembly
Cable Assembly
Bulb, #44
Sleeve, Blue
Sleeve, Red
Micre Switch
Switch Insulator
Nut Plate, 2·56
Mach. Screw, 2·56 x
1/2,
SL·PH
Wire Ramp, Top
Wire Ramp, Middle
Wire Ramp, Bottom
F-14 Launch Ramps Assemblies
&
Parts
(viewed from underside of ramps to show details and parts locations)
Item Part No.
1 C·11356
2 H-11598
3 24·6549
4 03·8063-1
5 03·8063·4
6 5647·12073-01
a) 01-8467
b) 01-8240
c) 4002-01052-08
7 12-6714
8 12-6712
12-6713
ELECTRONICS GAMES. INC.
3-37
