Page 111 - Williams BLUE Parts Catalog 16-9064-B

Knocker Assembly
1
Item Part No. Description
1 B-7409-2 Mounting Bracket
2 See chart Coil Assembly
3 23-6420 Rubber Grommet
4 A-5387 Coil Plunger Assembly
5 01-8-508-T Coil Retain Bracket
(Under Coil Assembly)
6 4008-01 017-06 Machine Screw
7 H-11835 Knocker Cable
Notes: 6-10686 is used on all previous games except Space Shuttle (535).
Drawing on p. 2-14 is void.
Knocker $-St Taxi Fire B-G S-F . Cye Banz
Assembly No. Coil Assembly 552 553 556 557 559 564 566
6-10686 AE-23-800-02 x x
8-10686-1 AE-23-800 x
B-10686-2 AE-26-1200 x x x x
ELECTRONICS GAMES, INC. 2-14a
