C-7196 (NEW) 10 STEP UNIT
FOR ALL GAMES ST.ARTING WITH I I PADDOCK I I -
STARTING WITH "B'ETAI1-ALL SHUFFLES a BOWLERS
411 DRUM UNIT
(NEW)
38-727 1
3A-7125
8-26-800.
('24 VOLT)
8 -28- 1450.
I (50 VOLT)
3C-7272
(NEW)
A-6295
fi
, ,I
I
SW-2U-12
LUBRICATION :
00 NO'T PUT LUBRICANT ON DRIVE AR~1ATURE .
PROPER LUBRICATION WILL INSUR E A LONGER LASTING AND BETTER
OPE RAT! NG UNIT
POINTS TO BE LUBRtCA 1-ED ARE THE THREE POSTS ON WHICH THE NYLON
PARTS ROTATE. EACH TOOTH OF THE RATCHET. ALSO THE: (2) DRIVE PAWL
GUIDE SLOTS, INDICATED BY *" .
" SERVICE SUGGEST ION"
IF' UNIT BECOMES SLUGGISH -DISASSEMB LE, CLEAN ALL PARTS AMO
REASSEM BLE. LUBRICA TING ALL PA,RTS MARKED VHiH *.
