GAME LUBRICATION GUIDE
Use only MBI Instrument
Grease available at all Williams Elec-
tronics, Inc. distributors.
Part No. 20A-8886 as indicated in chart
byX.
STEP AND REPLAY UNITS.
Do not lubricate solenoid plungers!
Drive, reset and lock arms pivot
X
Ratchet
shaft
X
Ratchet
teeth (metal)
X
Ratchet
pawl pivots
X
Torsion springs
X
Contact
disc segments and rivets
X
RELAY BANK ASSEMBLIES.
Do not lubricate solenoid plunger!
Crank arm pivots
X
Rear leg hinge pivots
X
Reset arm lift edge
X
JET BUMPERS
&
DISAPPEARING JET.
Do not lubricate solenoid plungers!
Bumper switch cup
X
Rods
X
Cam lock arm pivot
X
Bumper cam link pivots
X
Rollers
X
BALL EJECT
&
KICKER ASSEMBLIES.
Do not lubricate solenoid plunger!
X
Ejector or kicker pivots
X
Link
X
FLIPPER ASSEMBLIES.
Do not lubricate solenoid plunger!
Armature link
X
BALL RELEASE ASSEMBLY.
Do not lubricate solenoid plunger!
Fibre Link
X
Ball release lever pivot
X
