Page 210 - 1971_1972_WILLIAMS_CATALOG_ASPIRE

5
22 ••
~l '
18 ••
~::::~ ~~...., ___~15
---~
NOTE: When ordering parts be sure to specify the part
number, description, quantity, and model number of unit.
INDE.X NO. PART NO. DESCRIPTION QUANTITY INDEX NO. PART NO. DESCRIPTION QUANTITY
1 900926 Kicker Screw 1 13 405586 5c Magnet Gate Assembly 1
2 950030 #6 5/16xl/32 Viasber 1 14 951061 Thickness Screw 1
3 951051 Kicker 1 15 402-8 Keps Nuts-8-32 2
4 950069 Gate lever Spring 1 16 150-6-2 #6-32x~ Rnd. Head Screw
S 405551-2 Mainplate Assembly I -Sems 1
6 951055 Gate Pivot Pin 1 17 405552-1 Coverplate Assembly 1
7 900448 "C" Washer 2 18 950440 Bounce Tester 1
8 951071 5c Rail I 19 110-8-6 8-32x~ Rnd. Hd. Screw 2
9 405558 5c Gate Assembly 1 20 950005 Return Coverplate I
10 110·6-2 #6·32x V. Truss Head Screw I 21 951066·1 Coverplate 1
11 405620 5c Cradle Assembly 1 22 900818 Mounting Studs 4
12 901153 Upper Gate Pivot Spring 1 23 901154 lower Gate Pivot Spring I
