0- 7251 10 STEP 3" DRUM UNIT
WITH PRINTED CIRCUIT AND CONTACT RING.
38-7298
20A-8712 -25
38-7297
3C -7272 ---- --..
SW- IIMS-2
20A-88 15
20A-8712-12 }
81-26-800
(24 VOLT)
e A-7255 @
10A-314-1
18-5155
A-7254 SW-2M-3S
8 -7252
12A-6430
LUBRICATION:
DO NOT PUT LUBRICANT ON DRIVE ARMATURE.
PROPER LUBRICATION WILL INSURE A LONGER LASTING AND BETTER
OPERATING UNIT.
POINTS TO BE LUBRICATED ARE THE THREE POSTS ON WHICH THE NYLON
PARTS ROTATE. EACH TOOTH Of THE RATCHET. ALSO RATCHET CAM AND
TOP OF DRIVE PAWL- BRACKET, INDICATED BY*" .
" SERVICE SUGGESTION ."
IF UNIT BECOMES SLUGGISH -DISASSEMBLE. CLEAN ALL PARTS AND
REASSEM BlE ~ LUBRICATING ALL PARTS MARKED WITH *.
