COINCO
5J;RlES 78 s, SERIES 79
PE NNY COIN PAT .H
ADJUSTMENT FOR THE
PENNY PATH
When the penny is {rI se r-ted into the acc eptor it
pass es the quar ter and ni ck el tra nsf er cradl e to
the penny transf er cra dle wher e it is gauged fo r
corr ect diam e ter and expo sed to the w asher re-
talner wire, then direc ted to the penny runway of
the accept outlet .
There i s no -ctef inite adj us tment proce dure in the
pen ny p a th. Only cl ea nlines s of moving parts is
ess e .nt ia lto pro per ope ra tion. For this r-eason
it is imp ort ant tha t th e accept or be le ve l, the
penny un ders ize lever ope rat.e fr eely and abo ve
a ll~ th a t all scr ews are tight.
1~ ACCEPT
8
