Page 824 - BallyMidway YELLOW Parts Catalog 16-9147-B

Kit Parts
Video Game Kits ~cont'd
PIGSKIN (4004~K)
Part Number Description Qty.
A~8550~1 Potentiometer & Bracket Assy. 1
C~9214~4 Button Assembly, Red 2
C-9214~5 Button Assembly, White 2
C-9214~6 Button Assembly, Yellow 2
C-13246-4004-K 68000 Mini CPU Board 1
C-13581~1 49-Way Joystick Assembly 2
0·11581-4004 Audio Board 1
H-8866 Volume Control Cable 1
H-12746-1 Video Signal Cable
H-12758 Audio Board Jumper Cable 2
H-13257 Sound Power/Speaker Cable 1
H~13411 Jamma Cable 1
H-14023 Players 1 & 2 Cable 1
03-6047-18 Tubing Spacer, 3/16" 4
03-7933 Nylon Ty-Rap 1
03-8250 Control Panel Cover 1
16~4004~K~ 101 Kit Manual 1
16-8587-795 FCC Warning Label 1
16-8587-825 FBI Warning Label 1
16-8587-957 Game Serial Number Label 1
16-9048 Bally Registration Card 1
16-9155 Controls Template 1
20-9222 Palnut, 5/8" 8
20-9457 Button Holder w/Switch 8
31-1480-4004-K Screened Marquee 1
31-1481-4004-K Screened Control Panel Overlay 1
31-1482-4004-K Decal Sets 2
4308-01123-208 Bolt 8-32 x 1-1/4 CB 8
4408-01128-00 Nut 8-32 Keps 8
4608-01 081 ~11 H-F #8 x 11/16 PL-HWH 6
4608-01081-16 H-F #8 PL-HWH 7
5795-10703-24 20 Pin Ribbon Cable 1
9-38 @a!fy/MIDWAY
