Page 778 - BallyMidway YELLOW Parts Catalog 16-9147-B

Power Supply Switcher Assemblies
Term2 Total Super Strike
Part Number Description 40009 40010 40017 42413
Game and Part Quantity
A-14205 Power Supply Sw Ass'y x x
a) H-10217-4 Video Sw/Power Cbl 1 1
b) H-13953 Ground Jumper Cable 1 1
c) 01-9254 Shield 1 1
d) 01-9938 Mounting Bracket 1 1
e) 16-8587-701 High Voltage Label 1 1
f) '20-9700 PIS Switcher 12A 1 1
A-15202 Power Supply Sw Ass'y x
a) H-15203 Video Sw/Power Cbl 1
b) H-15206 Ground Jumper Cable 1
c) 01-10500 Mounting Bracket 1
d) 01-10573 Shield 1
e) 16-8587-701 High Voltage Cable 1
f) 20-9700 PIS Switcher 12A 1
C-13253-1 Power Supply Sw Ass'y x
a) H-10217-4 Video Sw/Power Cbl 1
b) H-13953 Ground Jumper Cable 1
c) 01-9254 PlSupply Terminal 1
d) 16-8587-701 High Voltage Label 1
e) 20-9633 PIS Switch 8SW 1
9-18d @af/r/MIDWAY
