Page 541 - BallyMidway YELLOW Parts Catalog 16-9147-B

Unique Parts for Specific Games - cont'd
THE ADDAMS FAMILY (20017)
Loop Assembly
A-14962
Item Part Number DesO"iption
1. A·14963 loop Sub-Assembly
2. 5647-12693-25 Switch
3. 5070·09054-00 Oiode1N40011.0A.
4. 01-8240 Nut Plate #2-56
5. 4002-01105-07 Mach. Screw, 2-56 x 7/16
6. 01-8600 Insulator
Note: See p. 5-111 for related Kicker Ass'y
plnA-15115.
Loop Lockup Assembly
A-14964
Item Pari Number Deso-iption
lockup loop Assembly
Switch Sub-Assembly
Diode,1N4oo11.0A.
Nut Plale '2·56
Mach. Screw, 2·56 x 7/16
Insulator
1. A-14965
2. 5647-12693-25
3. 5070-09054-00
4. 01-8240
5. 4002·0110S-07
6. 01-8600
Note: See p. 5-111 for related Kicker Ass'y
pin a-14107.
@af!tt/MIDWAY 5-105
