Unique Parts for Specific Games
Item Part Number
1 0-13306'
2 8-13496-1
3 C-13809
4 8-13629
Description
Ball Popper & Extention Assy.
Oiverter Assembly
2-Position Assembly
Oiverter Assembly
'See pp. 5-41 and 5-49.
3.) Diverter Assembly
8-13496 -1
Item Part Number Description
1 B-13493 Mounting Bracket Ass'y
2 AE-26-1S0Q Coil Assembly
3 A-l0821 Flipper Stop Brkt Ass'y
4 03-7066 Coil Tubing
5 01-8413 Coil Mounting Bracket
6 4010-01008-06 MS 10-32 x 3/8 P-PH (4)
7 470 '-00004 -00 LW #10 Split (4)
5-66 @a!fy/MIDWAY
