Page 481 - BallyMidway YELLOW Parts Catalog 16-9147-B

Unique Parts for Specific Games * cont'd
ATLANTIS (200B)
'~
~I
12
Top View
9
Back View
Back Panel Assembly
0-12622
Quantity
Item Part Number Description Used
B-12727-1 Lamp & Socket Assembly 1
2 01-9170 Gusset Bracket 2
3 4106-01114-08 TCS #6 x 112PL 11
4 C-12553 PCB Lamp Assembly 1
5 03-8149-13 Mini-Dome, Clear 2
6 03-8149-8 Mini-Dome, Amber 1
7 20-9521 PCB Lock.Standoff 4
8 31-1475-2006 Screened Back Panel 1
9 0017-00101-0371 MS #8-32 x 12 PH
10 03-7642-8 Plastic Insert, Tr, Amber
11 03-8269-9 Plastic Post, Tr. Red
12 4106-01019-26 SMS #6 x 1-5/8 RH
