Page 454 - BallyMidway YELLOW Parts Catalog 16-9147-B

Coil Assemblies for Kicker Arm and
Kickbig Arm Assemblies (Slingshot)
-- _.
KickerlKickbig Associated Coil Coli Assembly
Assembly Part No. and Bracket Assy. Part Number
A365-0521 0-0001 A365-00067 -0029
8-11051-R 8-9362-R-1 AE-23-800
8-11395 8-9362-1 AE-23-800
B-11395-1 8-9362-R-2 A365-00067 -0030
B-12665 8-9362-R-1 AE-23-800
C-12873 AE-26-1500
Kicker Arm Associated Coil Coil Assembly
Part Number and Bracket Ass'y Part Number
A-14874 8-11203-L-1 AE-26-1200
A-14875-1 8-11203-R-1 AE-26-1200
A-14875-2 8-11203-R-1 AE-26-1200
8-11203-L-1 AE-26-1500
8-12665 I 8-11203-R-1 AE-26-1500
8-14369-L I AE-27-1200
5-26 @a!fy/MIDWAY
