Page 449 - BallyMidway YELLOW Parts Catalog 16-9147-B

Kicker Arm (Slingshot) Assemblies - cont'd
A-14875-1 (Left)
Item Part Number Description Item Part Number Description
Coil Plunger Assembly 6 8-11203-L-1 Coil & Bracket Ass'y
Mounting Bracket Ass'y a) B-7572-1 Bracket & Stop Ass'y
Crank Assembly, Left b) 01-8-508-S Coil Retaining Bracket
Hairpin Clip c) 4006-01017-06 MS 6-32 x 3/8 P-RH (2)
FW .265 x .500 x 15 ga d) 4406-01119-00 Nut, 6-32 ESN (2)
e) AE-26-1200 Coil Assembly
f) 03-7066 Coil Tubing
7 10-128 Spring
1 A-5103
2 A-5653
3 A-14872-2
4 12-6227
5 4700-00030-00
A-14875-2 (Right)
(Parts listed replace same items of A-14875-1)
Item Part Number Description
3 A-14872-1
6 B-11203-R-1
Crank Assembly, Right
Coil & Bracket Ass'y
Note: See p. 5-22d for drawing.
@af!tt/MIDWAY 5-22c
