Page 446 - BallyMidway YELLOW Parts Catalog 16-9147-B

Jet Bumper Coil Assemblies
J~)
~'4l ~A ~./
.-:::
~- "~ §~-----~
5-22
8-9415-1
Jet Bumper Coli Assembly
Item Part Number
1
2
3
4
5
6
7
8
9
8·7417
01·1747
01·5492
01-5493
02-3406-1
10~326
AE-23-800
4006·01017·04
03-7066
Description
Bracket & Stop Assembly
Coil Retaining Bracket
Armature Link, Steel
Armature Link, Bakelite
Coil Plunger
Armature Spring
Coil Assembly
MS #6·32 x 1/4
Coil Tubing
@a!fy/MIDWAY
