Thumper Bumper Assemblies - cont'd
A365..(J51 00-0002
Item Part Number
Description
Item Part Number
Description
1
A360-00044-0000 Coil & Tubing Assy.
13
0017-00003-0501 Lamp #555, Wedge Base
a)
5070-09054-00
Diode lN4004GP, t.oA
14 0017-00031-0060 Lamp Socket
2
A365-07000-0004 Core Plug Assembly
15 0365-04700-0009 Plate
3
0017-00042-0452 Thumper Bumper Base
16
0017-00042-0460 Body, White
4
0020-00202-0000 Switch Plate
17 A-4754
Flange & Stud Assy.
5
A967 -00074-0100 Make Switch Plate
18
0017-00042-0444 Wafer, White
6
01-1;1116
Bracket
19
10-326
Compression Spring
7
01·9117
Mounting Bracket
20
0017-00103-0041 Nut #8-32 Locking
8
02-3406-1
Plunger
21
0017-00103·0052 Nut #6-32 Locking
9
0017-00104-0073 Spring Washer .515 i.d.
22
'A020-0009S-0211 Switch Assembly
10 0365-02950-0004 Plate
a)
5070-06258-00
Diode 1N4001, 1.0A
11 0365-04700-0010 Plate
12
0010-00274-0177 Compression Spring
C-12B42 and C-12842-1
Item Part Number
Description
Item Part Number
Description
1
AE-23-800
Coil & Tubing Assy.
13 24-8768
Lamp #55, Wedge Base
a)
5070-09054-00
Diode 1N4004, 1.0A
14 24-8813
Lamp Socket
2
B-12749
Core Plug & Brkt Assy.
15
Not used
3
03-8324-5
Thumper Bumper Base
16
03-8292·7
Body, Black
4
01-9166
Switch Plate
17
A-12854
Flange & Stud Assy.
5
01-9321
Make Switch Plate
18 03-6035-7
Wafer, White
6
01·9319
Bracket
19
10-326
Compression Spring
7
01-9117
Mounting Bracket
20
4408-01119-00
Nut #8-32 Locking
8
02-3406-1
Plunger
21
4406-01119-00
Nut #6-32 Locking
9
4705-00002-00
Spring Washer .515 i.d.
22
8-13267
Switch & Diode Assy.
10
01-9116
Bracket Plate
a)
5W-1A-187
Switch
11
01-9320
Plate, Bakelite
b)
5070-06258-00
Diode 1N4001, 1.0A
12
10-411
Compression Spring
*
03-6047-16
Spacer
*
Not used on all games.
Miscellaneous Hardware:
4005-01016-18B
4008-01015-04
4008-01 015·06
4008-01070-14
4108-01001-10
MS, 5-40 x
1/18
P·RH
TT, 8-32
x
1/4
P-PH
rr.
8·32 x
3/8
P·PH
MS, 8-32
x
7/8
HH
5MS, #8 x 5/8 P-PH-A
