Page 413 - BallyMidway YELLOW Parts Catalog 16-9147-B

Ball Eject Assemblies ~confd
Pool Radio Dude Harl Bugs
Assembly Part Number 2014 2015 2016 20001 20009
Game and Part Quantity
B-9361-R~1 -r 3
B-9361-R-5 1
B~9361-R-9 2
B-9361-R-5 B-9361-R-9
Item Part Number Description Item Part Number Description
1 A-6949-R Spring Plate 1 A-6949-R Spring Plata
2 A-7471~R Eject Cam 2 A-7471-R Eject Cam
3 A·80S0-1 Plunger Assy. 3 A-80S0 Plunger Assembly
4 A-826B Mtg. Bracket Assy. 4 A-8268-2 MIg. Bracket Assy.
S 10--362 Eject Spring 5 10-362 Eject Spring
6 12-6227 HairpIn Clip (2) 6 12-6227 Hairpin Clip (2)
7 4700-00030-00 FW .265x.500x.067 7 4700-00030-00 FW .265x.500x.067
8 4700-00103-00 FW .285x.SOOx.015 8 4700-00103-00 FW .285x.500x.0~ 5
9 AE-26-1500 Coil Assembly 9 AE-26-1500 Coil Assembly
10 03-7351-1-9 Eject Shield, Tr. Red 10 03-7351-1-9 Eject Shield. Tr. Red
Gillign PartyZ OrWho BRose Addam
Assembly Part Number 20003 20004 20006 20013 20017
Game and Part Quantity
A-15368* 1
8-9361-R-1 1
8-9361-R-5 1
*5ee p 5-110.
