Page 390 - BallyMidway YELLOW Parts Catalog 16-9147-B

4-26b
Rollover Wire & Bracket Assemblies - cont'd
Shooter Lane Rollover & Switch Assemblies
Gillign PartyZ DrWho BlackR Addam
Part Number Description 20003 20004 20006 20013 20017
Game and Part Quantity
A-11619 Shooter Lane Switch Ass'y 1 1 1 1 1
a) 01-8240 #2-56 Nut Plate
b) 01-8617 Mtg. Bracket
c) 4002-01105-07 MS 2-56 x 7/16 (2)
d) 5070-09054-00· Diode 1N4004 1.0A
e) 5647-12693-04· Mini-Micro Switch
·Updated part; same configuration.
(J?~/MIDWAY
