Page 374 - BallyMidway YELLOW Parts Catalog 16-9147-B

Ball Gate Assemblies - cont'd
RADICAL! (2015) Part Number Description
Quantity
Per Game
A-13301
a) 01-9477
b) a 12-6912-1
Ball Gate Assembly
Mounting Bracket
Gate Wire
2
1 A-13626
a) 01-9694
b) 12-6917
Ball Gate Assembly
Mounting Bracket
Gate Wire
See drawings below.
A-13627-1
a) 01-8240
b) 01-8600
c) 01-9654-1
d) 12-6909-2
e) 5070-06258-00
f) 5647-12073-11
Switch Gate Assembly
Nut Plate
Insulator
Mounting Bracket
Gate Wire
Diode 1N4001 t.OA
Mini Micro Switch
2
A-13627 -2 Switch Gale Assembly
Same as above except:
c) 01-9654-2 Mounting Bracket
d) 12-6938 Gate Wire '--- .__ ,___l ...L..- --'--- __''
4-24b @a!fy/MIDWAY
